ORPHEO 3
Shimano 3x9
$ 899.99
Key elements:
- Sporty Progressive Geometry for performance and comfort
- Alloy frame and fork
- Shimano 3x9 drivetrain
- Powerful hydraulic disc brakes
- Internal cable routing
Colors:
Technologies
3X9 Gearing
3X9 Gearing
Alloy Fork
Alloy Fork
Aluminum Frame
Aluminum Frame
Optimized Gearing
Optimized Gearing
Progressive Geometry
Progressive Geometry
XS-XL
XS-XL
Characteristics
Frame
Meta 20 aluminum
Fork
Aluminum tapered 1-1/4 to 1-1/8 in
Weight (lb)
24.8
Sizes
XS S M L L XL
Shifters
Shimano Alivio 3 x 9
Front derailleur
Shimano Altus
Rear derailleur
Shimano Altus
Brakes
Tektro HD-R280 hydraulic disc
Brakelevers
Tektro
Crank
Shimano FC-MT101
Chainrings
44-32-22
Bottom bracket
Shimano Sealed cartridge
Cassette
Shimano 11-28t
Chain
KMC-Z9
Headset
FSA Orbit integrated sealed
Handlebar
Alloy butted 12 mm rise
Stem
Promax
Grips tape
Velo ERGO dual density
Saddle
Opus City
Seatpost
Promax alloy 27.2 x 300
Wheels rims
Weinmann X-Star 19D
Hubs
Joytech
Tires
Kenda Kwick Tendril 700 x 35
Pedals
FPD NW-247
Other
Front and rear-rack and fender ready
Geometry
| Size | XS | S | M | L | XL |
| Rider’s height (± 5CM) | 155 | 164 | 173 | 182 | 191 |
| Rider’s height (± 2″) | 5’1” | 5’4.5” | 5’8” | 5’11.5” | 6’3″ |
| S – Seat tube | 380 | 420 | 460 | 500 | 540 |
| TT – Top tube | 529 | 547 | 568 | 589 | 611 |
| HT – Head tube | 113 | 131 | 154 | 176 | 196 |
| HA – Head angle | 71 | 71.25 | 71.5 | 71.75 | 72 |
| SA – Seat angle | 74.5 | 74 | 73.5 | 73 | 72.5 |
| CS – Chain stay | 435 | 440 | 445 | 445 | 450 |
| D – BB drop | 75 | 75 | 72.5 | 70 | 72 |
| ST – Stack | 540 | 560 | 580 | 600 | 620 |
| RE – Reach | 379 | 387 | 397 | 407 | 416 |
| SO – Stand over | 717 | 744 | 775 | 806 | 834 |
| Handlebar width (mm) | 580 | 600 | 600 | 620 | 620 |
| Stem length (mm) | 70 | 80 | 80 | 90 | 100 |
| Crank length (mm) | 170 | 170 | 175 | 175 | 175 |
