VIVACE 1
2018|2019
Archive
Key elements:
- Shimano Ultegra R8000 11-speed complete gruppo
- Shimano Flat Mount hydraulic disc brakes
- High performance and impeccable handling with American Classic Argent 30 wheels
Colors:
Characteristics
Frame
Gamma 30 Carbon
Fork
Gamma 40 Carbon Tapered 1-1/2 to 1-1/8 in
Weight (lb)
18.2 lb / 8.3 kg
Sizes
XS XS
Shifters
Shimano Ultegra R8020 2 x 11
Front derailleur
Shimano Ultegra R8000
Rear derailleur
Shimano Ultegra R8000
Brakes
Shimano Ultegra R8070 Flat Mount Hydraulic Disc
Brakelevers
Shimano R8020
Crank
Shimano Ultegra R8000
Chainrings
52-36
Bottom bracket
Shimano 86.5 mm
Cassette
Shimano 12-25
Chain
Shimano
Headset
FSA Orbit Integrated Sealed
Handlebar
Profile Design Drive
Stem
Profile Design 1/ZERO SEVEN
Grips tape
Velo VexGel Perforated
Saddle
Selle Italia X3
Seatpost
Opus Gold Carbon 27.2 x 300
Wheels rims
American Classic Argent 30 Centerlock
Hubs
American Classic Through Axle 12 mm Fr/Rr
Tires
Vittoria Corsa Graphene 700 x 25
Pedals
N/A
Other
KCNC Through Axles
Other
D12 Compatible
Geometry
| Size | XS | S | M | L | XL |
| Rider’s height (± 5CM) | 160 | 168 | 175 | 183 | 190 |
| Rider’s height (± 2″) | 5’3” | 5’6″ | 5’9” | 6’0” | 6’3″ |
| S – Seat tube | 470 | 500 | 530 | 560 | 590 |
| TT – Top tube | 520 | 544 | 559 | 579 | 594 |
| HT – Head tube | 114 | 132 | 150 | 171 | 192 |
| HA – Head angle | 71 | 72 | 73 | 73.5 | 73.5 |
| SA – Seat angle | 75 | 74 | 74 | 73 | 73 |
| CS – Chain stay | 405 | 407 | 407 | 409 | 409 |
| D – BB drop | 72 | 70 | 70 | 68 | 68 |
| ST – Stack | 520 | 540 | 560 | 580 | 600 |
| RE – Reach | 378 | 387 | 396 | 402 | 408 |
| SO – Stand over | 726 | 753 | 778 | 804 | 828 |
| Handlebar width (mm) | 400 | 420 | 420 | 440 | 460 |
| Stem length (mm) | 90 | 100 | 110 | 110 | 120 |
| Crank length (mm) | 170 | 172.5 | 172.5 | 175 | 175 |
