RECRUIT 4
27.5/29 Wheels
$ 799.99
Key elements:
- Lightweight trail inspired aluminum frame
- Suntour XCM-ATB HLO 100 mm fork with lockout
- Shimano 2x8 drivetrain
- Shimano MT200 hydraulic disc brakes
- xs/s - 27.5 inch wheels, m/l/xl 29 inch wheels
Colors:
Technologies
2X8 Gearing
2X8 Gearing
Meta 20 Alloy
Meta 20 Alloy
XS-XL
XS-XL
Characteristics
Fork
Suntour XCM-ATB HLO 100 mm with lockout
Weight (lb)
33.9
Sizes
XS S M L L XL
Color(s)
Dark Silver Dark Silver
Shifters
Shimano Acera 2 x 8
Rear derailleur
Shimano Acera shadow
Brakes
Shimano BR-MT200 hydraulic disc
Brakelevers
Shimano ST-EF505
Crank
Shimano FCM315
Chainrings
36-22
Bottom bracket
FP-B907
Cassette
Shimano HG200 11-34
Chain
KMC Z8.3
Headset
NECO semi-integrated
Handlebar
Opus Bronze 15 mm rise 31.8
Stem
Opus Bronze 6°
Grips tape
Velo Kraton
Saddle
Opus Endurance
Seatpost
Opus Bronze 31.6 x 350
Wheels rims
Ace alloy
Hubs
Shimano TX505/MT200B
Tires
CST Patrol 29 x 2.35
Pedals
FPD NW-420
Geometry
| Size | XS | S | M | L | XL |
| Rider’s height (± 5CM) | 155 | 163 | 170 | 178 | 185 |
| Rider’s height (± 2″) | 5’1″ | 5’4″ | 5’7” | 5’10’ | 6’1” |
| S – Seat tube | 380 | 400 | 430 | 460 | 490 |
| TT – Top tube | 551 | 575 | 597 | 635 | 647 |
| HT – Head tube | 95 | 100 | 105 | 110 | 120 |
| HA – Head angle | 68.5 | 68.5 | 68.5 | 68.5 | 68.5 |
| SA – Seat angle | 74 | 74.5 | 74.5 | 73 | 73 |
| CS – Chain stay | 450 | 450 | 450 | 450 | 450 |
| D – BB drop | 50 | 50 | 55 | 55 | 55 |
| ST – Stack | |||||
| RE – Reach | 380 | 380 | 420 | 440 | 450 |
| SO – Stand over | |||||
| Handlebar width (mm) | 720 | 720 | 740 | 740 | 740 |
| Stem length (mm) | 45 | 45 | 45 | 60 | 60 |
| Crank length (mm) | 170 | 170 | 175 | 175 | 175 |
